MODEL: TPI

Feature:

• Can be used in household or office building parking lot.
• Dual-cylinder lifting system, more stable
• Connecting shaft to make sure synchronous balancing
• Low post , faster lifting speed.
• Platform angle adjustable, can be used in low ceiling shop
• Single manual- lock release system , safe and reliable.
• Mold machining through the whole process so that the parts are universal and interchangeable
• Pass 120% capacity dynamic load text and 150% static load test.
• Italian oil seal to make sure no oil leakage

Safety :

• Limit switch
• Solenoid valve has the urgent manual lock release function.
• Optional manual pump on power unit in case of power off.
• Optional 24v control box，solenoid valve
• Optional ultrared rays alarm device, in case of unguarded entrance

TPI Specification

Car size	length	≤5000mm
	width	≤1850mm
	height	≤1550mm
capacity	≤1800 kg
motor	2.2kw
drive mode	hydraulic
lifting height	max 2100mm
Noise	≤63db

The specification is adjustable according to customer’s requirement
