MODEL: TPP
Feature:
- Can be used in household or office building parking lot.
- Posts can be shared, more economic and steady.
- Dual-cylinder lifting system, more stable and reliable
- Chain-equalization system
- Single manual or e-lock release system, safe and reliable
- Wear-resistant, heat-resistant and high strength macromolecular polyethylene slide blocks
- Optional wave plate or diamond plate , you can choose hot galvanizing,electroplating or powder spray
- Mold machining through the whole process so that the parts are universal and interchangeable
- Pass 120% capacity dynamic load test and 150% capacity static load test.
- Italian oil seal to make sure no oil leakage
- Solenoid valve has the emergency manual lock release function.
- Optional manual pump on power unit in case of power off.
- Optional 24v control box，solenoid valve and electromagnet
- Optional ultrared rays alarm device, in case of unguarded entrance
TPP specification
| car size | length | ≤5000mm |
| width | ≤1850mm | |
| height | ≤1550mm | |
| capacity | ≤2000 kg or 2700KGS | |
| motor | 2.2kw | |
| drive mode | hydraulic | |
| lifting height | max 2100mm | |
| Noise | ≤63db | |
- The specification is adjustable according to customer’s requirement
